Engineering Statics | P3/95 | 3D Equilibrium | Chapter 3 | 6th ed | Engineers Academy
Chapter 3: Equilibrium of Rigid Bodies 3D
The uniform rectangular panel ABCD has a mass of 40 kg and is hinged at its corners A and B to the fixed vertical surface. A wire from E to D keeps edges BC and AD horizontal. Hinge A can support
thrust along the hinge axis AB, whereas hinge B supports force normal to the hinge axis only. Find
the tension T in the wire and the magnitude B of the force supported by hinge B.
