Скачать или смотреть Night FPV Hexacopter 100W LED spotlight drone bar test Tarot 680 Pro

Fly with 100W led spotlight bar on the drone build onf tarot frame.

10x 10W High Power Cold White Led like 20000K 1000LM with 60 degree convex lens
10x 10W / 12V LED Constant Driver Power like 900mA
Small piece of aluminum from local store
drill, some screws and cords , thermal paste
Connect drivers to led one by one .
Power drivers connection in parallel to LiPo, you can add some receiver controlled switch like this https://www.hobbyking.com/hobbyking/s... for remote control.

1. Aluminium pice min. 23x3cm , a minimum thickless 2-3mm - it must be rigid . You can do spotlights lamp with other dimension, or but aluminium priece right after you ger leds so you can match and form your lamp.
With the dimensions 23x3 , you mount LEDs on the one aluminium site and drivers on the other
2. example drivers like http://www.ebay.com/itm/1-pcs-10W-12V...
3. example leds like http://www.ebay.com/itm/Lots-10-PCS-1... or cheaper, you have to look in your local stores or ebay of course :)
4. switch https://www.hobbyking.com/hobbyking/s... as above
5. Connect all like i write in film description
6. Do not turn on lamp without aditional cooling for long time - you must control temperature of aluminium (aditional coolink : wind from the propellers, low ambient temperature )
7. Do not touch the led, after a few seconds are hot
