Скачать или смотреть Vetronix MTS 5100 Getting Started version 2.0

A full copy of the instruction videos for the Vetronix MTS 5100 version 2.0

I made a copy of this because the original software only plays in older versions of Windows and decided to upload it in case it may be helpful to anyone else.

Note that the 'Operating Instructions' section is useless here as it's how to use the getting started CD but I included it for completeness and as an oddity.


Operating Instructions 0:11

Input/Output Ports 4:06

Display & Keypad 8:34

Unit Setup: Setup Utilities 10:37

Unit Setup: Tools Utilities 15:04

Ignition Analyzer: Vehicle Selection 18:37

Ignition Analyzer: Cylinder Display 20:28

Ignition Analyzer: Ignition Setup 24:45

Quick Check 27:24

DVOM 31:14

Graphing Multimeter 34:54

4-Channel Scope: Scope Setup 42:31

4-Channel Scope: Voltage & Time Settings 46:43

4-Channel Scope: Trigger Functions 51:41

4-Channel Scope: Cursor Operation 59:29

4-Channel Scope: Engineering Mode 1:04:27

Engine Test, Vacuum Waveform: Vacuum Calibration 1:06:59

Engine Test, Vacuum Waveform: Vacuum Waveform 1:08:50

Engine Test, Vacuum Waveform: % Vacuum/Cylinder 1:13:06

Engine Test, Cranking KV Test: KV Test Operation 1:15:16

Engine Test, Cylinder Test: Failed Cylinder ID 1:22:45

Engine Test, Cylinder Test: Cylinder Balance 1:31:23

Snapshot Recording: Snapshot Recording 1:40:12

Snapshot Recording: Saving Snapshots 1:47:26

File Manager 1:50:18
