After boarding at Huntingdon we headed down to Stevenage 365533 and 365527 took us here. As usual any trains that pass the window shall be noted like i do in my 'trains at' videos, including approach times to stations or crossings.

Class 365 info:

The British Rail Class 365 Networker Express are dual-voltage (25 kV AC and 750 V DC) electric multiple-unit trains built by ABB York from 1994 to 1995. These were the last units to be built at the York factory before its closure. They have received front-end cab modifications to equip them with cab air-conditioning, installed by WAGN, the design of which has given them the nickname "Happy Train", as a result of its 'grinning' air intake.

History:

In the early 1990s, the Networker family was entering large-scale service in the Network SouthEast sector – both third-rail 'Networker' EMUs (Class 465/Class 466) and 'Network Turbo' DMUs (Class 165/Class 166) were in service, with proposals for others, including a so-called "Universal Networker", intended as Class 371 and 381, that would have dual-voltage capability. However, by 1992, no work had been done in the development of these due to a lack of funding, so a replacement plan was required. For this, the Class 465 was modified for longer-distance services – a prototype was converted from an existing unit (designated as Class 465/3) to determine suitability, before funding was authorised for the purchase of 41 dual-voltage EMUs, each of four cars. These became the Class 365.

Description:

Although specified as a dual-voltage unit, Class 365s have never operated with this capability since they were built with only one system of traction current pickup. Units 365 501 to 365 516, which worked briefly for Network SouthEast before the franchise was given to Connex South Eastern, were originally supplied only with DC shoe gear for use on the 750 V third-rail system (with the exception of unit 365 502, which ran briefly on the AC network during testing and commissioning and was the main reason for this unit being chosen as the one subleased from Connex South Eastern to WAGN to bolster unit availability in the aftermath of the Potters Bar Crash in 2002). In this configuration the maximum speed was 90 mph (145 km/h).

When they transferred to West Anglia Great Northern for use with 25 kV AC overhead line traction supply, the shoes and associated equipment were removed and a Brecknell Willis high speed pantograph was installed, along with other operator and voltage-specific modifications and testing by Bombardier Transportation at its Doncaster Works, shortly before the works were closed.

However, the 365s retain the original 750 V DC bus, meaning that when on 25 kV overhead lines the current is collected as AC, rectified to DC for the onboard systems, and then inverted back to AC for the 3-phase traction motors. For running on overhead lines the maximum speed was raised to 100 mph (161 km/h).

Basic equipment consists of:

DMOC A – 4x Three-phase AC traction motors, traction inverter, sander
TOSL – Compressor, auxiliary converter, universal access toilet
PTOSL – Pantograph, transformer, auxiliary converter, small toilet
DMOC B – 4x Three-phase AC traction motors, traction inverter, sander
Dynamic (rheostatic) braking on the two Driving Motor coaches is available in addition to disc brakes, via a system of brake blending.

In common with the whole Networker fleet, wheel slide protection (WSP) operates on every axle. Under braking conditions a blowdown valve releases air from the brake cylinder of any axle if the rotational speed varies significantly from the average axle speed on the train.

Internal LED Passenger Information Display Systems (PIDS) and Auto-Announcers are fitted across the entire fleet.

Great Northern operations:

Great Northern, which took over the service formerly operated by First Capital Connect until 14 September 2014, and previously WAGN until 1 April 2006, uses Class 365s on outer-suburban services from King's Cross. These services are shared with Class 387 units. Services generally fall into two categories:

King's Cross to Peterborough
King's Cross to Cambridge, with some going on to Ely

These services usually stop more frequently than the Virgin Trains East Coast expresses with which they share the southern section of the East Coast Main Line, although there are exceptions, notably the non-stop service to Cambridge.

Starting from January 2014, the fleet has been undergoing a refurbishment by Bombardier Transportation at their Ilford site, some of which were completed on a two-part basis with a second stage starting from the summer of 2014. The first unit to be put back into service was 365 517, which began operations on 16 January 2014. The initial refurbishment comprises new seat upholstery, new flooring, interior and exterior repaint and an engineering overhaul to maintain reliability.
