DESIGN DETAILS
This Matlab design is based on development of three load flow analysis i.e., Backward Forward (BF), probabilistic load flow (PLF) and Newton Raphson (NR) techniques. The purpose of this design is to identify difference in power loss reducing by applying the 3 load flow models using HBMO in distribution system to evaluate optimal allocation and sizing of DG. The design tested using Matlab software on two standard radial bus system 33 and 69 considering below cases,
1. Basecase.
2. Only DG Placement.

The objective function,F(k)=min∑_(i=1)^br▒〖R_i*I_i^2 〗

RESULT EVALUATION PARAMETERS
1. Power Loss
2. Optimal DG Location
3. Optimal DG Size
4. Minimum and Maximum Voltage Bus Location
5. Execution Time

MATLAB SIMULATION FIGURES
1. Voltage Profile
2. Active Power Loss
3. Reactive Power Loss
4. Convergence Graph
