playlist :    • Engineering Graphics

Anna university question paper decoding
The top view of a line PQ has a length of 100 mm and makes an angle of 50 0 with horizontal. The end Q is in HP and P is in VP and 50 mm above HP. Draw the projection of the line and find the true length and true inclinations with the reference planes. Also locate the traces. (AU AM 2022 – 25.7.2022)
