Five Layers Plastic PE Air Cushion Bubble Film Extruder Machine
Basic Information
Model NO. CTJ-QDM
Type Sheet Extruder
Plastic Processed PE
Product Type Cast Film Extrusion Machine
Feeding Mode One Feed
Assembly Structure Integral Type Extruder
Screw Twin-Screw
Engagement System Full Intermeshing
Screw Channel Structure Deep Screw
Exhaust Exhaust
Automation Automatic
Computerized Computerized
Extruders 2
Air Bubble Layers 2, 3, 4, 5, 7
Material PE
Width of Product 600-1200;600-2500mm
Transport Package in wooden box
Specification 10*3*2.8m
Production Capacity 300sets/Month




Product Description

Air bubble film machine is for PE air-bubble film (also called as PE air-cushion film) is a generally used packing material
with the features of good shock absorption, impact resistance, sealability, corrosion resistance, transparency, etc. It is widely
used in the numerous fields of electronic products, precision instrument, daily necessities, glass, pottery, electrical household
appliances, furniture, hardware, toy, etc.












Model 7 layers
CTJ-QDM65Q CTJ-QDM90Q
Screw dia. mm Φ 65/ Φ 45/ Φ 65 Φ 90/ Φ 65/ Φ 90
L/D ratio L/D 30: 1/ 25: 1/ 30: 1 30: 1/ 30: 1/ 30: 1
Screw speed r/min 5-40 5-30
Air-bubble spec. mm (5-30) × (3-10) (5-30) × (3-10)
Width of product mm 600-1200 1200-2500
Installed capacity (approx) KW 100 130
Dimension (L× W× H) (approx) m 10× 3× 4 12× 4.5× 4
Total weight (approx) T 12 15
