Model: AP9997GK-VB
Silk screen: VBJ1101M
Brand: VBsemi
parameter:
Type: N-channel
Rated voltage (Vds): 100V
Maximum continuous current (Id): 5A
On resistance (RDS(ON)): 100mΩ @ 10V
Gate-source voltage range (Vgs): 20V (positive and negative)
Threshold voltage range (Vth): 2-4V
-Package: SOT223

Application introduction:
AP9997GK-VB is an N-channel field effect transistor (MOSFET) with a high voltage rating and moderate current handling capabilities. It is suitable for a variety of applications, especially those requiring high voltage switching and current control.

Detailed parameter description:
1. **Type**: This is an N-channel MOSFET, meaning it conducts when a positive voltage is input. This type of MOSFET is commonly used in switching and regulating circuits.

2. **Rated Voltage (Vds)**: The maximum drain-source voltage it can withstand is 100V. This means that under normal operating conditions, its voltage should not exceed 100V.

3. **Maximum continuous current (Id)**: The maximum current capability of this MOSFET is 5A. Although not very high, it is still sufficient in many high voltage applications.

4. **On-resistance (RDS(ON))**: RDS(ON) is the resistance in the on-state, which affects the power consumption and efficiency of MOSFET. At a gate-source voltage of 10V, its RDS(ON) is 100mΩ, indicating relatively low power consumption in the on state.

5. **Gate-source voltage range (Vgs)**: The gate-source voltage range of MOSFET is 20V, which means that a voltage of up to 20V is required to control its conduction state.

6. **Threshold voltage range (Vth)**: The threshold voltage range of this MOSFET is 2-4V. This is the gate-source voltage range that initiates conduction of the MOSFET.

7. **Package**: This MOSFET comes in SOT223 package, which is a small package suitable for small circuit boards and space-constrained applications.

Application areas:
AP9997GK-VB MOSFET is suitable for a variety of high-voltage electronic applications, including but not limited to modules in the following fields:

1. **Power switch**: Can be used for high voltage switching power supply, such as voltage conversion and power supply stabilization.

2. **Motor drive**: Used in motor controllers to control the speed and direction of the motor.

3. **Power Inverter**: Used in inverter circuits to convert DC power into AC power, such as solar inverters and power inverters.

4. **High voltage power management**: used in high voltage power management and current control circuits, such as industrial electronic equipment.

5. **Battery Management**: Used in applications that require high-voltage battery charge and discharge management to ensure safe and efficient battery use.

In short, this N-channel MOSFET is suitable for high-voltage electronic modules and equipment that require high-voltage switching and current control, providing power control and current management functions.
