Plastic pelletizing line with water ring pelletizer for squeezed PE plastic film and flakes
The water ring plastic pelletizing line is a highly efficient and reliable system for producing plastic pellets from molten plastic resins. This advanced technology combines precision engineering and robust design to deliver consistent and quality output, ideal for various applications in the plastics industry, especially for pelletizing the materials like PE films, scraps and flakes.
The water ring pelletizer works on the principle of centrifugal force and water cooling. Molten plastic is extruded through a die plate, forming strands. These strands are then cut into pellets by rotating knives as they pass through the die face of water ring pelletizer . The water in the chamber cools the pellets rapidly, solidifying them before they go into the dehydrator machine.
This water ring plastic pelletizing line typically consists of the following units:
1, material loader: usually use screw loader or belt conveyor for materials loading.
2, metering feeder: convey the material into the extruder evenly.
3, Extruder: single screw extruder is used for melting the plastic.
4, hydraulic screen changer: filter out the impurities to purify the plastic.
5, water ring pelletizer: cut the molten plastic into round pellets on the die face quickly, flow 6, vibration sieve: classify the pellets .
7, dehydrator: centrifugal dehydrator is hided under the vibration sieve, dewatering the pellets and transfer the pellets.
8, cyclone system: transfer and storage the pellets in a cyclone silo.
9, control system: for centralized control the working of the whole water ring plastic pelltizing line.
The video shows a single stage plastic pelletizing line with water ring pelletizing for making the plastic pellets from squeezed PE film, but this plastic pelletizer machine can be also used for PE flakes and scraps, it has 500kg/h output.
In MG machinery company, you can have other choice for different models of plastic pelletizing line with different configurations for different plastic materials. For example,
1, 100-200kg/h
2, 200-300kg/h
3, 300-400kg/h
4, 400-500kg/h
5, 600-800kg/h
6, 800-1000kg/h, etc.
To meet the pelletizing requirements for different plastics, we also provide the strand plastic pelletizing lines, so that you can make the plastic pellets from PE, PP, PET, PVC, ABS, PC, etc.
