Скачать или смотреть Ansys Fluent Tutorial for Turbomachinery: Flow Around a Compressor Blade with Periodic Boundaries

In this tutorial, I demonstrate how to set up and simulate flow around a compressor blade using periodic boundary conditions in ANSYS Fluent.

The main goal of this video is to clearly show the simulation workflow and setup process, including:

Defining periodic boundaries for a blade passage

Setting up rotating and stationary zones

Applying sliding mesh (mesh motion)

Running a transient simulation

Connecting interfaces properly between zones

Please note that this tutorial focuses on demonstrating the simulation procedure. For high-accuracy results suitable for research or industrial applications, additional steps such as mesh refinement, y⁺ verification, turbulence model validation, time-step sensitivity studies, and convergence analysis are required.

Sliding mesh and transient simulation are used to properly capture the physics of the rotating domain.

This video is especially helpful for those working on turbomachinery CFD using ANSYS Fluent.

If you find this content useful, don’t forget to like and subscribe for more turbomachinery and CFD tutorials.
