Скачать или смотреть How to Bend Sheet Metal in Creo (Bend Tool Step-by-Step)

In this video you’ll learn how to use the Bend feature in Creo Sheet Metal to create quick, clean bends without building full flanges. I show you the full workflow step-by-step: choosing Regular vs Roll, selecting Part Bend, setting inside/outside radius, sketching your bend line, controlling which side stays fixed, bending inward vs outward, and using bend relief options like stretch, rectangular, obround, rip, or no relief.

In this tutorial you’ll learn:

How to start the Bend tool (Regular vs Roll)

Feature choice: Part Bend vs Feature Bend

How to choose Inside Radius vs Outside Radius

How to pick a plane and set sketch references

How to sketch a proper bend line

How to set the bend location (both / center / offset options)

How to choose the fixed side (arrow + flip)

How to bend inward vs outward (flip direction)

How to set bend angle (90°, 25°, or custom values)

How to set bend radius (thickness, 2x thickness, etc.)

Bend relief explained: no relief, stretch relief, rectangular relief, obround relief, rip relief

How to edit the bend later (edit definition → sketch, angle, radius, relief)

Why bends are useful for fast sheet metal modeling

How bend lines appear when you resume the flat pattern
