I'll take you through the process of disassemble (No disassemble!) and reassemble (Johnny 5 ALIVE!) whilst performing a case upgrade from 3D printed to an acrylic one courtesy of www.misterfpga.co.uk.

NEW RETRO ADVENTURES | The games, toys and technology from the 💾 80s, 💿 90's and 🚀 beyond. If it looks like retro and smells like retro, we're doing it!

00:00 Intro
00:34 The New Case
01:40 Parts Overview
02:52 Assembling the MiSTer
05:32 The Result
06:28 Future MiSTer Content
06:55 Final Thoughts

⭐️ADDENDUM⭐️
Thanks to @ElectronAsh for the additional info!
-----------------------------------------
02:14 - That's actually the USERIO / SNAC port, for specific MiSTer peripherals like joystick adapters or the mt32-pi.
It just happens to use a USB 3.0 style socket, as it has enough pins, and the cables are commonly available.

03:55 - I would recommend that people unplug the SDRAM module before installing the IO Board.
This is just so you can see the pins on the IO Board that plug into the (single-row) "Arduino" header more easily.
Then make sure all of the pins are in the socket holes before pressing down on the IO Board.

(that should help prevent bending any of the pins, either on the IO Board or on the DE10's 40-pin header.)

Just make sure that the SDRAM module gets plugged in the correct way again.
On most of the common versions, the SDRAM chips face inward towards the FPGA, but always double-check your version.

(some people might say it's best to just leave the SDRAM module in place, to help reduce strain on the socket, which might be a fair POV.)
-----------------------------------------
