Gimatic SEXT has been created to be suitable in LV slide and LVP linear guide high performance applications such as high dynamic or by interpolated movement, which requires more accuracy than the standard transducers (SE series).

In LV slide and LVP linear guide applications, where the standard
SE series transducers (SE9ABZ1 and SE9ABZ1-HR) do not meet
the accuracy requirements or dynamics needed, external linear
position transducers can be employed.
This type of transducer has an active reading head
(SEXT20SIN020) combined with an adhesive magnetic strip
(SEXT20BAND015) that can be positioned on the sides of the LV
slides and LVP guides.
The reading head can be fixed to the LV slides using brackets
LV25-KIT-05 and to the LVP linear guides using brackets LV25-
KIT-15.
