EVERDIGM DTH DRILL RIGS_D700

Revolver Type Auto Tube Changing System
Electric / Hydraulic Joystick Control for Easy Operation
Center Auto Greaser System for Easy Lubrication
Auto Sensing Cooling System for Fuel Efficiency
Multiful Stage Compressor for Fuel Efficiency

■ Main Specifications
Hole Diameter Range : 4.5” - 7” (115 - 177 mm)
DTH Hammer Range : 6”, 5”, 4”
Drill Pipe Diameters : 3.5”, 4” and 4,5” (89, 102 and 114 mm)
Drill Pipe Length : 20’, 16’, 13’ (6 m,5 m,4 m)
Max. Hole Depth : 180’ (55 m)
Engine Output : 328 kw (440 hp) / 1,800 rpm
Air Delivery : 883 cfm (25 m³/min)
Air Pressure : Two Stages Screw Type, 25 bar
Transport Weight : 54,013 lbs (24,500 kg)
Transport Width : 8.2’ (2,500mm)
