Drawer slide profile and features:
.76mm(3") x 19mm(0.75") (Height x Side space)
.Finish in ZP , BZP(BLK) , B.E.D(BLK)
.Customized length from 10" to 60".
.Full extension travel
.Mounting by side or flat , Non-disconnect , Silenced

Load ratings:
Different application and use will influence the performance of slide.
.Moderate use 500lbs / pair
.Frequent use 400lbs / pair
.Mobile equipment (vehicular) 300lbs / pair
Flat mount 150lbs / pair

Applications:
This slide is designed for use in a variety of heavy duty storage applications.
.Large panty pull-outs
.Wide lateral file drawers
.Vehicular storage drawers

Specifications:
When slides installed in drawers that are wider than its deep are
subject to reduce their load carrying capacity. Same as, slides in
applications that are cycled frequently also carry a lower load rating.
Please consider this info. to determine the load rating of model 7688.
This slide can not use on any application supporting human weight as
injury may happen.
