IK-12 NEXT is the latest model of IK-12 series, one of the most popular and long- seller gas cutting carriage.

New control panel and torch set: Wide range of application is possible to enable not only gas / plasma cutting, but also welding with the same carriage.

Newly equipped function: “CREEP MODE” (Patent pending): By simply pressing the button, normal speed can instantly be switched to low speed mode for easy adjustment at start/end point of thick plate cutting.

Adding Weaving Unit option: Butt-welding for thick plat can be easily made by Weaving Unit.

No need to add a separate control box for plasma cutting and welding application. Signal interface is already implemented into the machine.

Features
Wide range of speed setting 40~2400 mm/min.
New control system allows wide range of application; gas/ plasma cutting and welding.
Stable and accurate speed control is achieved with encoder motor and digital speed indicator.
Easy speed control with “creep mode” at lead-in/ out of thick plate cutting. IK-12 Next directly inherits various options of IK-12 MAX3, which can be used as such.

Technical specifications

Model Name IK-12 NEXT
Stock no. 20506283
Travel speed 40-2400mm/min
Motor DC24V Encoder electronic control
Speed dial Infinite rotation multifunctional dial
Digital Display Travel speed and parameters
Max. load weight 50 KG

Gas cutting
Straight cutting (with the same rail for IK-12)
Circle cutting (with circle cutting rail or circle cutting attachment)
Creep mode

Plasma cutting

Plasma arc interlocking start
Arc test
Wait time for carriage running start 0.0 - 10.0 sec
Welding
Position Butt weld with straight downward position
Weld interlocking start
Arc test
Wait time for carriage running start 0 - 10.0 sec
Weaving control
Swing speed (mm/min) 400 - 1500mm/min
Swing range (mm) 0 - 100.0mm/min
Left/middle/right stop time (sec) 0.0 - 10.0 sec
Input Power Source Single phase AC100-240V 50Hz-60Hz

Body weight (KG) 8.5
Machine size (L x W x H) mm 432 x 220 x 160 (without stand part)
