Continuing the series based off of the Forrest M. Mims III books...
In this video we use a couple of normally open (N.O.) push buttons to see what happens when we use switches in parallel. The result is OR logic where switch 1 (SW1) OR switch 2 (SW2) must be pressed (closed) in order to activate the output which is an LED in the demonstration.

My Breadboard setup to mimic the RadioShack Learning Lab Kit -    • Using the LM317 to Create a Multi-Voltage ...

Chapters
00:00 - Circuit Overview
02:30 - Simulation
04:40 - Building The Circuit
