Скачать или смотреть NX 2312 What's New in Design - Algorithmic Modelling Offset Region node

This NX CAD video demonstrates the new functionality in the Siemens NX 2312 version release which was released in December 2023.

This video shows how Text on faces can now be Embossed.

Offset Region inside any number of closed curves on sheets and solids:
• Offsets a closed region of a sheet or contiguous faces with side-walls.
• Intelligently identifies nested loops of closed curves that are common in lettering
• Use optional input for Point in Region in case of ambiguity
• Outputs same entity type as the parent of the input faces

Benefits:
• Eliminates several operations for creating embossing from curve-based patterns
• Enhancement on Text on Face workflow basis customer request
