Скачать или смотреть S120 GFUVE 20K HZ BANDWIDTH 2000A CABLE FAULT ANALYSIS CLAMP ON CURRENT TRANSFORMER - MADE IN CHINA

The S120 is a general purpose 2000A AC Clamp current probe transformer designed for use with DMMs, cable fault analysis and loggers instruments that have a current input. It has a 1000:1 or 2000:1 ratio and output of 1mA per amp or 1mV per amp measured in the jaw. The S120 has an integral 2.5m or 5m lead terminated. The rounded jaw design on this clamp probe makes it well-suited for cable fault analysis applications where high accuracy and low phase shift and wide frequency.
APPLICATIONS
Power quality analyzer(PQA)
power and harmonic meters
Energy meter calibrator
Cable Fault Analysis
Measuring around cable bundles
Power load monitoring
Earth resistance meter
Large industrial loads
FEATURES
Measurement range of 10mA to 2000A AC
Improved ergonomic design & easy operation
High content nickel metal permalloy core
Frequency 10-20kHz
Holding wire diameter: φ120mm
Conforms to EN 61010, 600V CAT III
Transformation ratio: 1000:1, 2000:5
Low phase shift for power measurement
Designed for DMMs, recorders, loggers, oscilloscopes, power and harmonic meters
UL, CE mark
