Скачать или смотреть Making Insanely Light Weight Racing Drone Frame (Carbon Fiber)

In this video Joachim shows how he makes molds for extremely light weight 5 inch carbon fiber racing drones and then makes a frame with the molds. (Mainly done for testing, since arm repairs on this frame are more difficult than heavier carbon plate quadcopter frames. Wires can be put inside the arm with holes on the sides to improve aero)



Chapters:
00:00 CAD model of the drone
01:24 CAD model of the plugs
02:48 3D Printing the plugs
03:18 Plug preparation - Sanding PLA
10:13 Plug preparation - Joining halves
10:53 Plug preparation - Gap leveling
11:44 Plug preparation - Setting tolerances
14:33 Plug preparation - Gel coats
19:37 Plug preparation - Gel coat sanding
21:09 Plug preparation - Final tolerances
22:48 Plug preparation - Gel coat polishing
23:37 Mold making - Applying release agent
25:17 Mold making - Tooling gel coats
26:44 Mold making - Molding paste
29:25 Mold making - Finishing & separation
31:03 Mold making - Drilling holes
31:14 Mold making - Final result
31:25 Using the mold - Marking fabric templates
31:37 Using the mold - Making templates
36:34 Using the mold - Applying release agent
37:36 Using the mold - Carbon fiber layup
38:02 Using the mold - De-molding
39:04 Final result!
