Скачать или смотреть CATIA V5 | SPRINGS DESIGNS | HINDI TUTORIALS

THIS VIDEO CONTAINS DESIGN OF SPRINGS IN THE DESIGN TOOL CATIA,
A SPRING CAN BE SEEN AS A DEVICE THAT STORES POTENTIAL ENERGY, SPECIFICALLY ELASTIC POTENTIAL ENERGY, BY STRAINING THE BONDS BETWEEN THE ATOMS OF AN ELASTIC MATERIAL. MANY MATERIALS HAVE NO CLEARLY DEFINED ELASTIC LIMIT, AND HOOKE'S LAW CANNOT BE MEANINGFULLY APPLIED TO THESE MATERIALS.
DESIGNS MADE IN VIDEO:-
1. HELICAL SPRINGS OR COIL SPRINGS IT IS A SPRING WHICH IS MADE UP OF A WIRE COILED IN THE FORM OF HELIX. IT IS MADE TO HANDLE TENSILE AND COMPRESSIVE LOADS.
2. CONICAL AND VOLUTE SPRINGS THESE ARE THE COMPRESSION SPRING HAVE CONICAL SHAPES. THE CONICAL SPRINGS ARE WOUNDED WITH A UNIFORM PITCH WHEREAS THE VOLUTE SPRINGS ARE WOUNDED IN THE FORM PARABOLOID WITH CONSTANT PITCH AND LEAD ANGLES. UNDER COMPRESSION, COILS OF THESE SPRINGS SLIDE PAST EACH OTHER AND MAKE THE SPRING TO COMPRESS TO A VERY SHORTER LENGTH.
3. TORSION SPRINGS IT IS A SPRING THAT WORKS ON TORSION OR TWISTING. IT STORES THE MECHANICAL ENERGY WHEN TWISTED.
4. TENSION OR EXTENSION SPRING TENSION OR EXTENSION SPRINGS WORKS ON THE APPLICATION OF TENSION LOADS. WHEN TENSILE LOAD IS APPLIED TO THIS SPRING IT EXTENDS TO SOME LENGTH.
5. CONSTANT SPRING IT IS A TYPE OF SPRING IN WHICH THE SUPPORTED LOAD REMAINS THE SAME THROUGHOUT THE DEFLECTION CYCLE.
