Скачать или смотреть 2UR-GSE Lexus IS-F Timing Chain, Tensioner, Guide Tutorial Part 6 - Timing Chain Cover

Part six of the timing chain guide. Applies to the 2UR-GSE of the Lexus IS-F. Moving onto the timing chain cover

Here is my parts list with QTYs needed

11214-38040 VC gasket 1
11213-38060 VC gasket 1
11193-38030 spark plug tube seals 8
13521-38030 crank gear inner 1
13522-38030 crank gear outer 1
11229-38030 vc filter gasket 2
15193-38010 oil pump seal 1
90301-35006 timing cover gasket 1
96722-24030 oil filter housing oring 2
16326-38010 coolant tstat gasket 1
16325-38020 water inlet gasket 1
16341-38030 coolant outlet gasket 2
16271-38010 water pump gasket 1
15193-38030 scavenger gasket 1
15786-38010 scav oil pipe oring 2
90301-11019 scav oil pipe oring 3
12196-38010 oil filler gasket 1
90210-08045 VC stud washers 6
13540-38041 tensioner LH 1
13540-38020 tensioner RH 1
13552-38010 tensioner gasket 1
15678-46020 VVTI oil filter 2
90301-92004 timing control motor oring 2
90110-12012 intake cam hex bolt 2
13506-38030 timing chain large 2
13507-31020 timing chain small 2
13550-38020 tensioner small chain 1
13560-38021 tensioner small chain 1
13561-38060 chain damper 1
13561-38070 chain damper 1
13559-38030 chain slipper RH 1
13559-38040 chain slipper LH 1
90311-42036 front crank seal 1
11159-31010 cylinder head corner gasket 2
11159-38010 oring lifter guide to VC 2
96761-35035 coolant pipe oring 2
90301-09028 dipstick tube oring 1
90301-A0029 fuel pump orings 4
23915-46011 fuel pump insulator 2
23224-38010 fuel pump gasket 2
23279-74010 fuel pump pulsation damper gasket 4
