Northland Stainless Steel Inc, 2000 Liter, 528 gallon, 316 stainless steel, single wall, with full internal pressure mixing tank. Vessel dimensions: 48" ID x 66" straight wall. Equipped with dome top, 16" ID bolt down man way, top flange mounted prop style mixer has 9" OD flange with (8) 3/4" bolt holes on 3-1/2" centers, also (3) 2-1/2", (1) 2", (1) 3" and (2) 5" OD sanitary top ports with CIP spray balls. Full side and bottom full Internal pressure rating of: MAWP 50 psi @ 300 Deg F and MDMT of -20 Deg F @ 50 psi. Dish bottom has 2" OD staintary center bottom discharge valve with 24" floor clearance without valve 30" floor clearence and mounted on (3) stainless steel legs. UL Rated and National Board # 821

OAD: 54" Diameter x 138" High
