🧠 Optimize LED Display Control with Data Group Swap & Split Settings in Colorlight Software

This video offers a step-by-step tutorial on how to configure Data Group Swap and Split Styles using Colorlight’s LED Setting software. These configurations are essential for ensuring accurate image alignment and avoiding data overload when controlling multiple LED modules.

📘 What You’ll Learn:

Understanding Key Concepts
• What is a data group and how it controls RGB signals
• Why data group swapping is necessary for correct screen output
• Types of split styles (no split, 2-split, 4-split, same-direction split)
• Maximum data group capacity (8192 pixels) and firmware support for up to 8 splits

Step-by-Step Configuration in LED Setting
• Login to LED Setting and access “Receiver Parameters”
• Identify your cabinet’s actual split connection (e.g., same direction 2-split)
• Choose correct split style from software options

Performing Data Group Swap
• Use “Intelligent Mode” to auto-detect and assign data group positions
• Recognize white squares on modules to match groups
• Mark unused output ports as “Empty Group” if no signal is detected
• Finalize and save parameters to the receiving card

🎯 This guide is ideal for LED technicians and system integrators working with Colorlight receiving cards, especially in scenarios involving non-standard module layouts or extended data paths.

🛠 For additional split or pixel capacity beyond standard firmware limits, please contact Colorlight engineers directly.
