Скачать или смотреть Creating connections with the DT and DTM plug-in system [strong and resilientt]

00:00-00:05 Introduction
00:06-01:29 Overview
01:30-01:56 Differences DT and DTM Series
01:57-03:14 Making robust connections
03:15-04:09 Releasing connections
04:10-04:29 BuddyTip: Secondary Interlocks
04:30-04:50 Plug-in distributor DT series
04:51-05:49 Packaging units
05:50-06:15 Poster Releasing principles+Housing competence
06:16-06:27 Conclusion

This video is all about the DT and DTM plug systems. Our Workshop-Buddies show you how easy it is to use our DT plugs and DTM plugs. This way you can easily create strong and waterproof connections.

The DTM and DT connector systems are particularly suitable for use in harsh conditions. That's why DTM and DT connectors are often used in agriculture, where connectors are exposed to a lot of dirt and grime. A DTM or DT connector can also withstand ambient temperatures from -55°C up to 125°C without any problems. Our DTM plugs and DT plugs are certified according to IP68, so they are fully protected against dust and permanent immersion in water.

If you use a 1.5 mm2 cable, up to 13 A current load per contact is possible with a DT plug connection. The DTM connectors were developed based on the strengths of the DT connectors. They are intended to meet the demand for multi-pole plug connections with low current ratings. Therefore, up to 7.5 A current load per contact is possible for connections with a DTM plug when a cable with 0.5 mm2 is used.

With the DTM and DT connector system, you can easily make strong and watertight connections. In this tutorial, the Workshop-Buddies explain to you exactly how to make a DTM or DT plug-in connection. They also show you which tools are best suited for working with the DT and DTM connector system.

You can get the DTM plugs and DT plugs from us not only individually, but also in practical assortments. This means you always have the right DTM or DT plug at hand! That's why our DT plug assortment contains 236 parts and the DTM plug assortment 254 parts. Our DTM and DT connector assortments include socket and pin housings as well as contacts and mounting clips.

Under the following links you will find more information about our articles from the video:

⬇ Downloads
Poster releasing principles: https://herthundbuss.com/en/download/...

📕 Online-catalogue
DT plug-in system: https://herthundbuss.com/en/online-ca...
DTM plug-in system: https://herthundbuss.com/en/online-ca...

🖥 Website
Product range installation: https://herthundbuss.com/en/products/...

🤖: AI-generated Voices
