BB-5 – Offset Flange | Bolt Holes Out of Line is live!
In this Blueprint Bootcamp workout, we take on an Offset Flange with bolt holes that don’t play by the rules — testing your ability to think beyond symmetry and accurately place features in unconventional layouts.

Download the PDF here https://drive.google.com/file/d/1aARZ...

You’ll practice:
✅ Positioning hole patterns that aren’t centered or evenly spaced
✅ Managing symmetry and offset distances in sketches
✅ Building from 2D to 3D with precision and intent

💬 Challenge Question:
Can you rebuild this drawing without assuming symmetry — and still nail every bolt hole location?
