Carr Lane Manufacturing Co. COO Colin Frost discusses the principles of Locating in this video.
Locators are one of the key elements in any jig or fixture solution, constraining the degrees of movement of a workpiece.
In common CNC machining applications, workpieces need to be constrained on both the X and Y Axis. This is commonly performed with three locating pins.
Locating principles are a varied and complex topic. For additional technical information on solving your workpiece challenges, visit Carr Lane Manufacturing.
--
Since 1952, Carr Lane Manufacturing Company has been committed to being the world’s preferred source of tooling components by continuously improving products, processes, and services to exceed our customers’ expectations.

Carr Lane Manufacturing provides a large selection of tooling components, clamps, fixturing and related workholding products for all areas of manufacturing. Based in St. Louis, Missouri USA, we make tooling items for virtually every industry around the globe. Carr Lane Manufacturing delivers consistently high-quality products and is certified ISO 9001-2015.

More information on the principles of location in Jigs and Fixtures: https://www.carrlane.com/engineering-...
