Скачать или смотреть Mori Seiki NT4250/1500S Multi Axis CNC Lathe, 2007 - Multi Spindle, Under Power, Inspection Ready

MSX-711T3 Control

Capacity:
Max Swing Of Workpiece: 28.7"
Swing Over Cross Slide: 28.7" (Turret 2 - 15.7")
Max Distance Between Centers: 73.3"
Max Turning Diameter: Tool Spindle: Capto C6: 25.9"
Turret 2: 13.7"

Max. Turning Length: 62"
Bar Work Capacity: 2.6/2.6" Spindle 2

Travel:
X-Axis Tool Spindle: 29.5"
Y-Axis Tool Spindle: +/- 8.3"
Z-Axis Tool Spindle: 64.4 + 3.9" for ATC
B-Axis Rotation Range Tool Spindle +- 120°
X2-Axis Turret 2: 7.7"
Z2-Axis Turret 2: 60.0"

Spindle 1:
Max Spindle Speed: 5,000 min-1
Number Of Spindle Speed Ranges: 2 Winding Change-over
Type of Spindle Nose: JIS A2-6
Through Spindle Hole Diameter: 2.9"
Min. Spindle Indexing Angle: 0.0001°
Spindle Bearing Inner Diameter: 4.7"
Spindle Torque 20 min/cont : 264/194 ft. lbf
Option: 336.3/264/194 ft. lbf 25% ED/15 min/cont

Spindle 2:
Max Spindle Speed: 5,000 min-1
Number Of Spindle Speed Ranges: 2 Winding Change-over
Type of Spindle Nose: JIS A2-6
Through Spindle Hole Diameter: 2.9"
Min. Spindle Indexing Angle: 0.0001°
Spindle Bearing Inner Diameter: 4.7"
Spindle Torque 20 min/cont: 264/194 ft. lbf
Option: 336.3/264/194 ft. lbf 25% ED/15 min/cont

Tool Spindle:
Number of Tool Stations: 1
B Axis Indexing Time 0.6s/90° Option 0.4
Min B-Axis Indexing Angle: 1° Option: 0.0001°
Max. Tool Spindle Speed: 12,000 min-1
Taper Hole Of Rotary Tool Spindle: BT40, Capto C6-HSK A63
Inner Diameter of Rotary Tool Spindle Bearing: 2.7"
Tool Storage Capacity: 20 Option 40,100
Max Tool Diameter With Adjacent Tools: 5.5"
Max Tool Length: 15.7"
Max Tool Mass: 17.6 lbs
Option 22.o=0 lbs.
Tool Changing Time Tool-to-Tool : 1s
Spindle Torque (10% ED/cont.) : 88.5/32.5 ft. - lbf

Turret 2:
Number of Tool Stations: 12
Turret Indexing Time: 0.25 s
Shank Height For Square Tool: 1.0"
Shank Diameter for Boring Bar: Max 2"
Max. Rotary Tool Spindle Speed: 6,000 min-1
Spindle Torque (15% ED /5min/cont.) : 29.5/22.1/11.1 ft. lbf.

Feed Rate:
Rapid Traverse Rate:
X1: 1,968.5"/min.
Z1: 1,968.5"/min.
Y: 1,181.1"/min.
X2: 1,181.1"/min.
Z2: 1,181.1"/min.

Motors:
Spindle 1 Drive Motor 20min/cont: 20/15 HP Option 30/20 HP
Spindle 2 Drive Motor 20min/cont: 20/15 HP Option 30/20 HP
Tool Spindle Drive Motor 10 min/cont: 24.7/15 HP
Coolant Pump Motor 60 Hz/50Hz : 1.40/0.84 HP x1
0.69/0.43 HP x 2 With Turret 2: 0.69/ 0.43 HP x 3

Coolant Tank Capacity : 97.7 gal.

Machine Size:
Machine Height From Floor : 108.9"
Floor Space Width x Depth : 191.6" X 118.5"
Weight: 51,920 lb.
