TANK T-26
CHARACTERISTIC DETAILS
DESIGNER Vickers-Armstrongs, OKMO (Leningrad)
DESIGNED 1928–1931
BASED ON Vickers 6-Ton
MANUFACTURERS Factory No. 232 (Leningrad), Factory No. 174 K.E. Voroshilov (Leningrad), STZ (Stalingrad)
PRODUCED 1931–1941
VARIANTS Mod. 1931, Mod. 1933, Mod. 1938/1939, T-26E
QUANTITY ~10,300 tanks and ~1,700 derivative vehicles
DERIVATIVES See Derived Vehicles
WEIGHT 8.6 - 10.5 t
LENGTH 4.65 m
WIDTH 2.44 m
HEIGHT 2.12 - 2.24 m
ENGINE GAZ T-26, 90-97 HP
MAXIMUM SPEED 31 km/h
MAXIMUM RANGE 220–240 km
CREW 3 (commander, gunner, driver)
ARMOR 15 mm (standard versions), 15-40 mm (reinforced versions T-26E)
PRIMARY ARMAMENT 7.62 mm DT machine guns (T-26 Mod. 1931), 45 mm 20-K gun (T-26 Mod. 1933 and later)
SECONDARY ARMAMENT 7.62 mm DT machine guns


TANK BT-7
CHARACTERISTIC DETAILS
DESIGNER KMDB
BASED ON BT-5
MANUFACTURERS KhPZ in Kharkov
PRODUCED 1935-1941
VARIANTS Mod. 35, Mod. 37, BT-7M, BT-7A
QUANTITY 5,753
DERIVATIVES BT-42
WEIGHT 13.8 - 14.65 t
LENGTH 5.66 m
WIDTH 2.29 m
HEIGHT 2.42 m
ENGINE Mikulin M-17T or Kharkov V-2, 450-500 HP
MAXIMUM SPEED 62–86 km/h
MAXIMUM RANGE 350-700 km
CREW 3 (commander, loader, driver)
ARMOR 10-22 mm
PRIMARY ARMAMENT 45 mm Mod. 1934/38 gun (20-K) or 76.2 mm KT-28 howitzer
SECONDARY ARMAMENT 1-3 DT machine guns


TANK T-60
CHARACTERISTIC DETAILS
DESIGNER Nicholas Astrov
DESIGNED 1938-1941
MANUFACTURERS Factory No. 37 (Moscow/Sverdlovsk), GAZ (Gorki), Factory No. 38 (Kirov), Factory No. 264 (Stalingrad)
PRODUCED 1941-1943
QUANTITY 5,417 + 594 conversions T-40, + 260 chassis for BM-8-24 (of which 12 were "T-40")
DERIVATIVES TACAM T-60
WEIGHT 5.8 t
LENGTH 4.1 m
WIDTH 2.3 m
HEIGHT 1.75 m
ENGINE GAZ-202 or 203, 70-85 HP
MAXIMUM SPEED 44 km/h
MAXIMUM RANGE 450 km
CREW 2 (driver and commander/gunner)
ARMOR 15-35 mm
PRIMARY ARMAMENT 20 mm TNSh automatic cannon
SECONDARY ARMAMENT 7.62 mm DT machine gun


TANK T-34
CHARACTERISTIC DETAILS
DESIGNER M. I. Koshkin (JMDB)
DESIGNED 1937–1940
MANUFACTURERS See Production
PRODUCED 1940–1945
VARIANTS T-34-57, T-34-85
QUANTITY 84,070
WEIGHT 26.3 - 30.9 t
LENGTH 6.68 m
WIDTH 3 m
HEIGHT 2.41-2.6 m
ENGINE Járkov V-2-34, 500 HP
MAXIMUM SPEED 53 km/h
MAXIMUM RANGE 250–330 km
CREW 4 (driver, gunner, commander/loader)
ARMOR 45-70 mm
PRIMARY ARMAMENT 76.2 mm L-11 or F-34 gun
SECONDARY ARMAMENT 2 x 7.62 mm DT machine guns


TANK T62-A
CHARACTERISTIC DETAILS
DESIGNER OKB-520
BASED ON T-55
MANUFACTURERS Uralvagonzavod (UVZ)
PRODUCED 1961–1975 (USSR)
QUANTITY 22,700
WEIGHT 37 t
LENGTH 6.63 m
WIDTH 3.3 m
HEIGHT 2.4 m
ENGINE Diesel V-55, 581 HP
MAXIMUM SPEED 50 km/h
MAXIMUM RANGE 450-650 km
CREW 4 (commander, gunner, loader, driver)
ARMOR Turret: 97-242 mm, Hull: 46-102 mm
PRIMARY ARMAMENT 115 mm U-5TS (2A20) gun
SECONDARY ARMAMENT Coaxial 7.62 mm PKT machine gun, 12.7 mm DShK anti-aircraft machine gun
