■ HP PageWide Color 556 Printer "Chipless Solution Initial Setup Printer"
Future Smart Bundle Version 4 -

00:00 Thumnail
00:01 Please remove the two bolts on the back of the printer
00:04 Separate the back panel of the printer and detach the firmware module attached to the mainboard.
00:06 Prepare the Jig components. (3.3V adapter, BlackZero, SD card reader, gender, firmware module)
00:08 Attach the firmware module and the gender.
00:12 Attach the firmware module and the gender to the SD card reader.
00:13 Attach the SD card reader to the BlackZero.
00:16 Connect BlackZero to the adapter.
00:18 Start BlackZero JIG Write.
00:20 Version Check Touch.
00:23 Start Touch → Writing No Chip FW...
00:26 Check the green shade (Writing No Chip FW completed)
00:28 Power on the printer.
00:33 Select Language → Select Region → Select Date.
00:45 Insert the cartridge without a chip.
01:00 Insert A4 paper → Close the main door.
01:06 Initialization completed.
01:08 Print the Consumables Status page from the report after Setup is completed. While the gauge fills from 0 to 100%, 6 alignment pages will be printed. (Head alignment process)
01:23 Print the Configuration page (to check printer version)
01:28 Also print the Consumables Status page.
01:37 Check if they are printed and then open/close the main door.
01:42 Please attach the continuous ink supply system to the cartridges.
01:54 Close the main door.
01:55 Previously used genuine HP supply installed.
01:57 Rebooting the Printer.
02:09 Check that the ink gauge is full, then power the printer off and on again.
02:15 After powering the printer off and on, you will see the R10:NC mark indicating certification.
02:19 Print the status page to confirm the certification.
02:29 After confirming the R10:NC certification, remove the chips.
02:40 After removing the chips, you wil see the non-chip certified status.
02:42 So far, we've learned about initial setup and authentication method Thanks for watching.
