Скачать или смотреть R36H Built-in WiFi, Serial and more (XNL R36 'ModChip')

IMPORTANT NOTE: This is a DIY project and does require a bit of soldering skills and might cause damage to your R36 if you're not careful.

I do NOT offer support for/about this project, I explain in the video and on the website why that is though😊

Often during developing with, on or for the R36 units I need an active network connection to SSH into the console, while at the same time often also needing the USB port. Well that would usually not possible with these units, since we only have one USB port for data. My project (the XNL R36 'ModChip') solves this problem once and for all😊

[SPONSOR LINK (REFERRAL)]
Get your own PCB's super cheap from JLC PCB as low as $2 without absurdly high minimal order requirements 😊: https://jlcpcb.com/?from=XNL

[DOWNLOADS AND RESOURCES]
The XNL R36 ModChip Download: https://www.teamxnl.com/xnl-r36-modchip/
RTL8188FTV Driver Installer: https://www.teamxnl.com/r36-rtl8188ft...
ArkOS Installation Tutorial:    • Installing or Updating ArkOS/dArkOS on you...
R36 WiFi Installation:    • Cheap Wifi For Your R36S & R36H

NOTE: All download mentioned here can be downloaded for free and DO NOT require you to signup for anything in any way😊👍🏽

[Time Stamps]
00:00 Hook & Intro
00:24 Project Introduction & Why
01:00 ('Failed') Experiments & Reverse Engineering
02:10 Sponsored Section (Ordering PCB's)
03:40 R36S NOT Supported!
04:43 Basically just and USB Hub
05:15 Disassembling the R36H
06:54 Confirmed Compatible Boards
07:15 Verifying Compatibility Yourself
07:38 Assembling the XNL R36 'ModChip'
09:24 OPTIONAL - RS232/Serial Connector
10:01 Installing the WiFi Module (RTL8188FTV)
13:15 Installing the XNL R36 'ModChip' Board
14:54 OPTIONAL - Drilling Serial Port Hole
15:53 If you DON'T want a WiFi On/Off switch
16:30 Connecting The Boards
19:29 Board Test (before WiFi Switch)
20:32 Installing WiFi On/Off Switch
21:56 OPTIONAL - Serial Wires (RX/TX)
22:57 OPTIONAL-RECOMMENDED Extra Capacitor
25:13 Why I Don't Offer Support!
26:18 Final word & Outro Ft. ‪@SophieThePigeon‬
