HYDRAULIC STUFFER MODEL TORSADO
(MAKE: DADAUX, FRANCE)
Feature:-
a) Torsado stuffer is ideal for manufacturing portioned and twisted merguez sausages
b) It permits to save a lot of time in comparison with continuous stuffers, it is also very precise (+/-5 gr)
c) Entirely in stainless steel
d) Delivered with 3 nozzles: ø 14-20-30
e) Pressure manometer. Closed hydraulic circuit
f) The portioner is very precise and adjusted from 0 to 10 000 g
g) Programmable number of portions
h) Programmable twister from 0 to 10 turns
i) Dosage and calibration
j) Complies with CE standard
k) Natural casing can be used on this machine

Production : About 150 portions per min. For weight from 50 to 60 gr. About 200 portions per min. For weights from 10 to 15 gr
Memory : 60 programs in portions per twist. 60 programs in twist per portion

Functions of Programmer
a) Weight of portions
b) Number of twist turns
c) Calibration in accordance with the density of product
d) Temporization between the portion and the twist
e) Temporization between the twist and the portion
f) Quantity of material remaining in the tank
g) Possibility to proportion without twisting
h) Possibility to count the portions with stopping at the target
i) Work in automatic (a pulse on the knee piece for starting and stopping the cycle) or
j) Work in semi-automatic (Keeping of the knee piece during the cycle)
k) Possibility to get the programming in different languages (on demand)
l) Including Automatic Hand (Twisting Device)

Technical Specification:-
Model : TORSADO
Power Supply : 3 Ph, 380 V, 50 Hz
Motor : 2.6 kW
Capacity : 32 L
Dimension : 700 x 745 x H 1046 mm (H 1570 mm with programmer)
Net weight : 380 kg approx.
