Matrix Tool, Inc. is excited to exhibit with our partners Sodick-Plustech and RJG at NPE2024: The Plastics Show, taking place in Orlando, Florida from May 6th to 10th. Visit the Sodick-Plustech booth #W3581, to witness this award-winning 4-cavity LCP micro injection mold in action!

Specifications:
Part Weight: 0.106g (requiring only 5 pellets of LCP)
Mold Dimensions: 4.5 × 5.0 × 5.9 in.
Four-Cavity Cold-Runner Tool with Fast Cycle Times
Sodick 20-Ton High-Response Micro IMM
Over 60 Knife-Edge Tooling Features
Each opening on the part is crafted by mating cores from both mold halves, featuring wall thicknesses as thin as 0.0048 in., slightly thicker than a human hair.
Features front and back-half ejection, incorporating multi-directional alignment interlocks and linear ball-bearing guided ejection.
Innovative design enhances alignment accuracy, improves cooling efficiency and reduces the overall footprint of the mold.
Mold Fill Time: ≤ 0.16 seconds, surpassing the performance of conventional injection molding machines.
2021 Plastics Technology Hot Shots Awards Recipient
