This model is mainly used for producing PC/PMMA LED lampshades, which come in various monochrome or lampshades such as semi-circular, square, and circular. Equipped with different extrusion and shaping molds, it can be used to produce other plastic profiles
Mainly used for producing PC fluorescent tubes, LED fluorescent tubes (LED fluorescent tubes), PC tubes, transparent two-color tubes, frosted tubes, and fluorescent tubes. The types of tubes include glossy, two-color, frosted, sandblasted, light diffusing, semi-circular, etc.
The entire production line consists of extruders, shaping molds, vacuum cooling systems, belt conveyors, fixed length cutters, and finished product stacking racks
Equipment features
1. The machine has the characteristics of high-speed operation stability, high output, etc
2. Electrical control system: The electrical part is controlled by a frequency converter, the motor uses Siemens motors, Omron temperature controllers, and the heating system uses cast aluminum heating coils
3. Both the screw and the barrel are made of high-performance alloy steel, which has advantages such as wear resistance, corrosion resistance, and high strength. The heating section of the material barrel has two structures: grooved and smooth sections, which meet the needs of different raw materials.
4. Temperature control system: The temperature control adopts Omron intelligent temperature control meter from Japan, dual PID intelligent control, and Schneider solid-state relay.
5. Mold: Using S136 mold steel, different materials of mold steel and designs are adopted according to the characteristics of different materials, achieving multiple strips per piece.
6. Vacuum shaping table stainless steel sink
7. The traction machine adopts belt type and variable frequency control
8. Use a fixed length saw blade for cutting and a set of motion pneumatic propulsion system; Installation form of saw blade: suspended inclined feeding to ensure error free products.
