Скачать или смотреть FLA by TECOI: Fully-Automated CNC Laser for Round Tube | Pipe | Square Tube | Various Other Profiles

MAIN CHARACTERISTICS:
The models of FL® series are the solution suitable for the cutting processes of pipes and profiles using plasma, oxyfuel and solid-state laser, being able to enable an area of the machine for flat cutting and beveling.
The possibility of automation in the load and unload of pipes allows a considerable saving in the processes of work and times of production. This model is called FLA®.

SPECIFICATIONS:
• Equipped with l solid-state laser/fiber laser TruDisk ™, plasma and oxyfuel.
• TECOI’s exclusive BEVEL ARC® beveling system.
• Maximum working width up to 2,000 mm. (78”) and length up to 18,000 mm. (60 ft)
• DFP® system for maximum flexibility and performance with both thin and thick materials.
• Round pipe diameter up to 1,200 mm. (47”) and square profile/max. rectangular up to 400x400 mm. (15,7”x15,7”)
• Positioning speed up to 110 m./min. (360 ft)
• Bidirectional integrated cover.
• Possibility of plate/sheet cutting, pipes and profiles area or combined systems.
• Equipped with FANUC™ activating and controlling systems. It includes touch screen, absolute encoder and communications through fiber optics.
• S.P.C.® system for detailed piercing control and S.A.C.-L® to minimize collision effects.

Quantum Machinery Group is a Leading U.S. Supplier of Metalworking Equipment.
NEW Machines in stock and readily available for immediate shipment.

Quantum Machinery comprises of a Full Sales Team with Before & After Sales Support, A Full Parts Department, and a Team of Trained Technicians, along with Turnkey Packaging, allowing us to assist you every step of the way; ultimately earning us the title as your One-Stop Shop for ALL of your Metalworking Machinery Needs.

Call or email our Quantum Machinery Sales Engineers Today for your Next Machinery Purchase!! - (909)476-8007 | Sales@QuantumMachinery.com

Quantum Machinery Group specializes in, offers, and stocks:
• Roll Benders / Angle Rolls
• Plate Benders / Slip Rolls
• Press Brakes
• Cold Saws
• Band Saws
• Tube and Plate Laser Cutting Systems
• Rotary Benders
• Iron Workers
• Shears
• Cutting Lines
• End Formers
• Twisting/Scrolling Bending Machines
• Horizontal Press Brakes
• Broaching Machines
• End-Wrought Iron Machines
• Gas Forges
• Iron Embossing Machines
• Presses for Locks
• Welding Positioners
• De-Burring Machines
• And more!!

Visit us online at - www.QuantumMachinery.com or come visit us at our Showroom, located at:
10270 Birtcher Drive
Mira Loma, California 91752

Our Website: http://www.QuantumMachinery.com
