PROBLEM 3
Determine the ultimate moment capacity of a reinforced concrete T-beam with the following properties: Flange width bf = 500 mm, web width bw = 320 mm, effective depth d = 530 mm and slab thickness t = 120 mm. Assume f’c = 32 MPa and fy = 415 MPa. The beam is reinforced with 10-32 mm bars.
