Скачать или смотреть Universal lathe RYAZAN 16K40 x 3000 mm

Manufactured by Ryazan (Russia)
Work piece diameter, mm 800
Work piece length, mm 3000
Max work piece weight, kg 2000
Spindle rotation speed, rpm 6.3 x 1250
Spindle bore diameter, mm 110
Metric threading, mm 1 – 224
Inch threading, thread/inch 28 – 1/4
Module threading, module 1/4 – 56
Pitch threading, pitch/diam. 112 – 0.5
Quill taper Morse 5
Quill movement, mm 240
Motor capacity, kW 15
Machine weight, kg 7120
Machine dimensions, mm 5780 x 1850 x 1620

Heavy duty lathe is in excellent condition. It is equipped with inverter, automatic and rapid feeds. Electrical system with Siemens controller, ABB 15 kW motor and all wire has been changed.
