Скачать или смотреть Fusion 360 From Zero | Beginner Step-by-Step Modeling Tutorial #03

Exercise - 3
3D Sketch : https://www.3dmechanism.com/post/3d-c...

Donate PayPal: https://www.paypal.com/donate/?hosted...

In this CAD tutorial we'll use the features:
Revolve
Definition: Creates a 3D solid or surface by sweeping a sketch profile around a central axis. How it works:
Profile: You draw the cross-section of your object. Imagine slicing a chess piece or a car wheel in half vertically—that cut face is your profile.
Axis: You select a line (usually a center construction line) to act as the hinge.
Operation: Fusion spins that profile 360° (or a specific angle) to create the solid. Best for:
Machined Parts: Shafts, axles, pulleys, and gears.
Vessels: Bottles, cups, and vases.
Spheres & Toroids: Creating balls or donuts/o-rings.

All dimensions are in mm/g/s/ISO
---------------------------------------------------------------------------------------------
