Скачать или смотреть Q2.1 - A Square Prism base 40mm & height 65mm, has its axis inclined at 45°...😃 - PROJECTION PROBLEM

Follow Engineering Drawing Playlist:    • Engineering Drawing [FULL COURSE]🔥

A Square Prism (base 40mm and height 65mm) has its axis inclined at 45° to the ground and parallel to V.P. The edge of the base which is nearest to the ground level is 10mm above the ground. Draw its, F.V., T.V. and L.S.V. view using 1st angle projection method.

UEM Kolkata, IEM Kolkata, IEM Newtown, IEM Saltlake, UEM Jaipur, Engineering Drawing, First year
Projection of Solids problem of UEM Assignment 2 question 1 (2.1)
Engineering Drawing question explained in english easily. This can be understood by anyone.
Engineering drawing Full guide.
Projection of Solids explained.
STEP by STEP Explaination.
