Скачать или смотреть Part 1 - IMSAI 8080 MPU-A CPU Board Assembly - Resistors - RTR511

Resistors - Video one of four.
In this video we begin assembly of the MPU-A 8080 based CPU card for the IMSAI 8080 computer. This video covers both an original PCB along with the reproduction PCB provided by IMSAI/Parastream Technologies.
If you purchased your kit from IMSAI/Parastream Technologies you'll have the supplemental documentation shown in the video.
The board can be assembled using the original IMSAI 8080 documentation that can be found by searching the web however the build will go a bit easier with the supplemental information.

Suggested tools:
A lead forming tool will help with the install of the resistors and diodes.
You can search AMAZON for "electronic component lead bender"
https://www.amazon.com/CANADUINO-Bend...

An IC lead forming tool will make it easier to insert the ICs into the sockets.
Jameco Electronics has this tool. It's part number 99363. Jameco is one of my preferred suppliers.
https://www.jameco.com/webapp/wcs/sto...
You can also search AMAZON for "dip ic chip lead straightener"
https://www.amazon.com/s?k=dip+ic+chi...

An inexpensive IC removal tool and the one I use most often can be found here:
https://www.jameco.com/z/08-609-HT103...
