In this CAD tutorial we'll use the features:
1. Extrude
Definition: Creates the main solid body.
How it works: You sketch a profile and pull it into a solid block or cylinder.
Best for: Creating the base shape (e.g., a curved pipe or a slanted housing).

2. Offset Plane
Definition: Creates a sketching canvas parallel to a face but at a specific distance away.
How it works:

The Problem: You want to create a screw mount that stands 10mm above the main surface, or you want to slice a flat spot into a cylinder.

The Solution: Select a standard plane (or a face) and drag the Offset Plane arrow to the exact height you need. Now you can sketch on this invisible "glass table" floating in space.
Best for: Positioning features precisely in 3D space without relying on existing geometry.

3. Hole
Definition: Drills a precise standard opening.
How it works:

The interaction: You place the hole center point on your Offset Plane.

The "Reach": The Hole tool can be set to cut from that floating plane down into the solid body below.
Best for: Counterbored bolt holes that need to sit at a specific height.

4. Fillet
Definition: Rounds off intersections.
How it works:

The "Weld": When you add a mounting boss to a main body, the connection is a sharp 90° angle (weak).

The Action: Adding a Fillet at the base distributes stress and makes the part moldable.
Best for: Strengthening the connection between the boss and the main body.
All dimensions are in mm/g/s/ISO
---------------------------------------------------------------------------------------------
