1. ANSYS Discovery AIM allows you to rapidly simulate static magnetic fields and current conduction to quickly evaluate the electromagnetic performance of your designs.
2. ANSYS Discovery AIM includes a guided workflow for magnetostatic simulation with an adaptive solution that allows you to rapidly compute magnetic fields, current density, Ohmic loss, inductance, magnetic force and torque.
3. ANSYS Discovery AIM also includes easy-to-use magnetic-thermal-stress coupling, which allows you to use the Ohmic loss as a heat source to compute the temperature distribution and subsequent thermal deformations and stress.
4. ANSYS Discovery AIM is an ideal solution for simulating the electromagnetic and thermal performance in fuses, actuators, buss bars, sensors and coils.
