Скачать или смотреть High Striker/Hau den Lukas Hammer - DIY (Part 5 of the Hau den Lukas Project)

#HaudenLukas #DIY #Hammer

Part 1: Preparations and first parts
Part 2: Together with other Makers on the Maker Hub in @Hassan Abu-Izmero workshop continue to build the Hau den Lukas until the first test
Part 3: Reworking, painting and optimization of the mechanics
Part 4 Electronics - Getting LEDs, sensors and printed circuit board ready
Part 5: Building the hammer
Part 6: Finished project

This is a do it yourself project, which was built on the occasion of the Maker Hub Event, which was organized by Hassan. An ingenious meeting at which various projects were developed and great friendships were made. This is a Hau den Lukas in self-construction. With a big hammer you hit the seesaw and it shoots a sledge up the mast. A great game to see who is the strongest ;-). On the mast are digital LEDs. These visualize the highest level at a stroke. The height of the sledge is measured at several places by means of Hall sensors. The controller/board is designed for this project and was assembled by myself. It can be programmed using Arduino IDE.
The hammer is made of stainless steel and steel and gets two thick rubber attachments. The handle is made of ash wood and then varnished.

Advertising
Thanks to Stahlwerk Schweissgeräte, Weicon and Next PCB for the support.

https://www.stahlwerk-schweissgeraete.de

TIG Welder: Stahlwerk DC WIG 200 ST IGBT
MIG/MAG Welder: Stahlwerk: MIG 200 ST IGBT
Plasma Cutter: Stahlwerk CUT 60 ST IGBT
#stahlwerkschweißgeräte #stahlwerk #stahlwerkcut60 #stahlwerkwig200 #stahlwerkMIG200 #MIG200 #CUT60 #WIG200


https://www.weicon.de
Parts for the bondings: VA250 black, Surface Cleaner, Activator

https://www.nextpcb.com
Printed Circuit Board for the Controller.
