Measuring the three feedback coils, inductance and capacitance and their coupling factor. Extra build info for the two inner coils, the high current coil (HC) and the center output coil (OC).
The outside high voltage (HV) coil is described in the previous video.

Inhave choosen to first give out this info before giving out the circuit design and showing what it does.

Support the research and JOIN to become a channel member.
Or donate:
https://paypal.me/masterivo

chapters
00:00 - intro
00:21 - Coil geometry
01:35 - wire source for OC and HC coil
02:19 - Measurements
02:21 - separate coil measurements
02:39 - HV inductance by itself
03:00 - OC inductance coupled to open HC coil
03:19 - HC coil inductance coupled to open OC
03:31 - Capacitances between the coils
04:11 - capacity between OC and HC (shorted out)
04:49 - Measuring the three coupled coils
05:30 - capacity between HV and OC coils (shorted, HC is open)
05:47 - capacity between HV HC coils
05:58 - Capacity between HV and HC coils (OC open, others shorted out)
06:48 - inductance while coils are coupled
07:00 - HC inductance (others open ended)
07:16 - HC inductance with OC shorted out
07:46 - HC inductance with HV shorted out (OC open)
08:09 - HV coil inductance (others open)
08:48 - HV inductance with HC coil shorted out
09:06 - OC inductance (others open ended)
09:42 - OC inductance (HC shorted out)
09:53 - Coupling coefficient
10:07 - OVERVIEW OF MEASURED VALUES
10:22 - INTER COIL CAPACITANCES
10:50 - coil inductances (others open ended)
10:57 - INDUCTANCES WITH CLOSED COILS
11:19 - coupling values (k)
12:04 - More build info
12:23 - inner coils build process
19:20 - OUTRO
