www.cementl.com The ammonium sulfate pipe reactor system is specifically engineered for acid-base chemical neutralization with high reaction precision and safety. Within the pipe reactor, liquid sulfuric acid is atomized and mixed with ammonia gas at high velocity, forming fine ammonium sulfate crystals in a controlled thermal environment. The exothermic reaction heat is efficiently utilized to partially evaporate moisture, reducing downstream drying load. When this reactive slurry enters the rotary drum granulator, it coats the recycled seed particles and solidifies into compact, uniform pellets. This integrated reaction–granulation process eliminates the need for separate neutralization tanks, mixers, or aging systems, significantly shortening the production flow and reducing both operational costs and environmental impact. The result is a highly automated system capable of continuous, stable operation with minimal operator intervention.
In fertilizer manufacturing, product uniformity and mechanical strength are crucial to ensure consistent nutrient delivery and prevent dust losses during transport or application. The rotary drum granulation unit in this system features optimized internal configurations—such as adjustable lifters, spraying nozzles, and internal steam pipelines—that promote efficient mixing and controlled granule growth. The use of steam-assisted granulation enhances the plasticity of material surfaces, allowing rapid formation of dense, spherical granules. The resulting ammonium sulfate pellets exhibit high compressive strength, low moisture content, and improved anti-caking performance, meeting international standards for agricultural and industrial fertilizers. Additionally, the product can serve as a raw material for compound NPK fertilizers, enabling flexible integration into multi-nutrient production systems.
From an engineering perspective, the Pipe Reactor Rotary Drum Granulation System represents a sophisticated chemical–mechanical integration designed to maximize process efficiency and minimize emissions. The process layout typically includes a reaction pipe, granulation drum, rotary dryer, cooler, screening unit, coating drum, and recycling system. Waste gases containing ammonia and dust are captured and neutralized through acid scrubbers and cyclones, achieving near-zero emissions in compliance with environmental regulations. The energy recovery system utilizes reaction heat and exhaust gas to preheat raw materials, further improving energy efficiency. Compared to conventional granulation processes, the pipe reactor design reduces ammonia slip, improves reaction utilization rates, and cuts down on sulfuric acid consumption—resulting in lower production costs and smaller carbon footprints.
Another defining advantage of this technology lies in its process flexibility. The same system can be adapted for other nitrogen-based fertilizers such as ammonium nitrate, ammonium phosphate, or compound ammonium sulfate–nitrate blends, simply by adjusting reactant ratios and feed conditions. This flexibility allows fertilizer producers to respond quickly to market demand shifts without major equipment modification. The granulator drum’s design supports variable speed control, adjustable retention time, and different feed recycling ratios—offering precise control over granule size distribution and nutrient concentration. The system can produce pellets ranging from 2–5 mm in diameter, ensuring compatibility with global fertilizer spreading equipment and agricultural practices.
Beyond the technical aspects, the pipe reactor rotary drum granulator aligns perfectly with modern sustainability goals in fertilizer production. Its closed-loop operation minimizes liquid effluents and gas emissions, while integrated dust collection ensures clean and safe plant environments. The reduced acid consumption and high conversion efficiency contribute to lower raw material waste and environmental burden. Moreover, ammonium sulfate itself—rich in sulfur and nitrogen nutrients—is a highly efficient fertilizer that supports balanced crop nutrition, improving yields and soil sulfur content, particularly in sulfur-deficient regions. The system’s scalability, ranging from small-scale 30,000 tons/year setups to large-scale 300,000 tons/year plants, makes it ideal for both emerging and established fertilizer manufacturers.
