Скачать или смотреть LED Flasher Circuit using BC547 | PCB Design Step-by-Step

Description: PCB Design of LED Flasher using Astable Multivibrator (BJT)

In this video, we design a LED Flasher circuit using an Astable Multivibrator configuration with BJTs and convert the schematic into a PCB layout. This is a classic electronics circuit widely used to understand transistor switching and timing principles.

An astable multivibrator continuously switches between two states, producing a square wave output that causes LEDs to blink alternately.

🔎 Topics Covered:
✅ Converting schematic to PCB layout
✅ PCB routing and grounding tips
✅ Final PCB output preview

This project is ideal for students of Electronics, Electrical Engineering, and beginners learning PCB design and transistor circuits.
