Скачать или смотреть How to add a Spindle to your CNC

I upgraded from my previous CNC to a larger Onefinity Journeyman X50 cnc. Since I went for a bigger machine I decided to go for it and add a water cooled spindle to my setup. This is part 1 where I wire up the spindle and the VFD to make sure it all works. This was definitely a learning experience and took awhile to make sure I did it right.
In the 2nd part I get into the details on programming the VFD so that the spindle is controlled by the Onefinity controller. These setup steps can be applied to other cnc setups using this spindle and CNC combination.

Some of the links below are affiliate links which help me keep making video

Onefinity website to check out the machine i'm using:
https://www.onefinitycnc.com/?ref=van...

Amazon Affiliate links to the items I used in the video.
Huanyang VFD Kit : https://amzn.to/3XVG5o8
VFD Extention Cable and box: https://amzn.to/3P040P4
Soldering Iron kit: https://amzn.to/3UvHEWQ
10-22 Wire Strippers: https://amzn.to/3iBOugm
Power Cord: https://amzn.to/3un9p9l
ER20 Collet (if yours doesn't come with one) https://amzn.to/3OZHFRE

4 Core Shielded cable came from Igus.com Part #Cf6-15-04
I ordered about 10 feet
Clear tubing came from my local Ace hardware. 3/16 inner diameter.
