Скачать или смотреть xSignals and Length Tuning in Altium Designer

Nine Dot Connects is no stranger to complex high-speed designs with very tight timing constraints. While length matched signals may be aesthetically pleasing, the effort required to obtain the end result can be daunting. The concepts involved include matched single and differential signals, T-branches, daisy-chain (fly-by) routing, and serial terminations. In order to efficiently deal with these issues the proper use of tools such as Length Tuning and xSignals is critical.

This webinar will show the functionality of both Length Tuning and xSignals in Altium Designer. Given that we have not covered the creation of differential signals in Altium Designer in prior webinars, a brief primer will be given.

In addition to some tool instruction, Tom Cassidy, our resident expert in DDR3/4 and other high speed copper configurations, will demonstrate ‘real world’ uses of both features. There are many tips and tricks that can make the process more efficient.

Would you like to see other webinar recordings or videos from us? Check out https://ninedotconnects.com/knowledge or reach out to us at [email protected] or 214-699-7719. Thanks!
