Скачать или смотреть XP600 Alignment Part 3: DC Motor & Carriage Accuracy

This video is Part 3 of the XP600 print head alignment series, where I focus on the DC motor and explain its direct relationship with carriage movement, dot placement, and print accuracy.

Unlike stepper motors that control paper feeding, the DC motor controls the carriage movement of the print head. If this motor is not properly synchronized, even a perfectly aligned stepper motor and clean encoder film will still result in:

Shadowing

Double images

Blurred text

Inaccurate dot placement

In this video, I explain what the DC motor actually does, how it interacts with the encoder system, and why poor DC motor behavior breaks piezoelectric ink spraying accuracy.

This episode builds on:

Part 1: Alignment fundamentals & motor roles

Part 2: Stepper motors & paper control

And prepares you for Part 4, where everything comes together in practical alignment and fine calibration.

If you want to truly understand XP600 alignment, this part is not optional.
