This 20 inch 48V 1500W single side shaft motor fat bike conversion kit combines the full E-bike technology: direct drive Brushless Gearless high torque hub Motor to change almost every bicycle into a personal electric bike. Save energy, protect environment and save money with a lot of fun.

Saving 10% of electricity, Improve the efficiency of 8% With The Newest Materials Steel Rotor.
Main Features:
. Rim: 20 × 3 inch double wall Alloy Rim Fit For: 20 × 4.00" tire
. Spoke: 12 gauge / 72mm Length × 36 pcs

. Engine: Bldc hub motor
. Voltage: 48V
. Power: 1500W
. Efficiency: 90.5%
. Max speed: 39.7 kmh -- 24.6 mph
. Mechanical brake: Disk
. Cable location: shaft end
. Cable length:100cm / 40"
. Noise: 60 db
. Surface: Black painted

. Driver: brushless controller
. MOSFET: 12 PCS
. With LCD: YES
. Rated Voltage: DC 48 Volts
. Min. Voltage: DC 40 ± 0.5 V
. Rated power: 1500 Watts
. Casing material: aluminium
. Maximum Current: 40 A ± 1 Amps
. Thermal: aluminum shell and the substrate
. 3 phase 120° brushless motor
. Operating Conditions: -20~45 °C
. Waterproof design
. Size: 171 mm L × 82 mm W × 42 mm H

With LCD, More Function:
Cruise
Forward & Backward Optional
Kmh & mph Optional
Max speed 0 ~ 72kmh
Pedal assist  0 - 5
Battery gauge
...

Package Content:
1 x 20 inch 48V 1500W beach snow fat tire single side shaft motor wheel
1 x 48V motor controller
1 x LCD
1 x Twist throttle -- Cable length: 1500mm
1 x Brake levers -- Cable length: 1500mm
1 x Three button switches control cruise, reverse .. -- Cable length: 1500mm
1 x Pedal assist -- Cable length: 900mm

Net Weight: 11.1 kg
Package Size: 50cm L x 50cm W x 27cm H
Package Type: Cardboard Box
